154 - Gomito inclinato (0° - 11°)

154 - Gomito inclinato (0° - 11°)

Angle joint adjustable for slopes from 0° to 11°, often used where top rail meets end upright on sloping sites.

Please also see our Interclamp Assist range of flush fittings to help compliance with the Disability Discrimination Act (DDA) and the Building Regulations Part M:2004.

Lista Giunti Stampare < Precedente Successivo >

Dati del prodotto e dimensioni

Dimensions Image 1 - 154 - Gomito inclinato (0° - 11°)
Dimensions Image 2 - 154 - Gomito inclinato (0° - 11°)
Dimensions Image 3 - 154 - Gomito inclinato (0° - 11°)
Dimensione a (mm) Peso (Kg) Box Qty* GTIN / EAN No
  B34   46   0.43   72   5060511021272
  C42   60   0.65   35   5060511021289
  D48   68   0.84   26   5060511021296

* Fittings are sold individually and do not need to be bought in box quantites. Box Quanties may be subject to change without prior notice.

Figures given as guidance only, dimensions and weights are subject to manfacturing tolerances and may be altered without prior notice.

Do not perform any pre-drilling, tube cutting, casting uprights or any other dimensionally critical processes prior to receiving fittings.
